The lab used to run Mastodon on Kubernetes: PostgreSQL, a Redis-compatible cache, and S3-shaped media storage on top of the usual edge stack. That worked, but it was heavy for a small personal instance — more moving parts than the workload justified.

The fediverse home at this-is-fine.social now runs snac instead: a minimal ActivityPub server in portable C, no database, all state on a single filesystem tree, backed up off-cluster with the same VolSync + restic pattern as other stateful apps.

Pocket ID is a small OpenID Connect provider — enough for a homelab without Keycloak. The lab runs it at https://auth.this-is-fine.io with Flux and an HTTPRoute on Envoy Gateway. Below is how Zot uses native OpenID against that issuer.

If you already run a homelab IdP, the interesting part is how little application code must change when the app speaks OIDC natively. Zot is a clear example: configure issuer URL, client ID, and redirect URIs, mount a secret, and the registry UI handles login without an OAuth sidecar in front of it.

Harbor is a full registry product: scanning, replication, projects, and several backing services. On aarch64 it is also heavy, and it was a poor fit for four RK1 boards (ARM support is still catching up). After moving Talos from x86-64 to ARM64, Harbor stayed disabled in Git; Zot serves oci.this-is-fine.io instead.

Harbor shines when you want built-in scanning UI, replication policies, and a large operations surface. The lab mainly needed push, pull, sign, and admit — a smaller registry that speaks OCI and runs comfortably on ARM boards was the better fit.

You can get MetalLB-style service IPs without MetalLB. Cilium includes a BGP control plane that advertises LoadBalancer addresses on the LAN. The lab peers worker nodes with a UniFi UDM-SE as the default-gateway iBGP peer so phones, laptops, and the tailnet can reach Envoy Gateway VIPs without NodePorts.

Without BGP (or something like MetalLB), a LoadBalancer Service on bare metal often sits Pending forever. Advertising routes into the LAN gateway fixes that: the UDM learns /32 (or the pool) and forwards traffic to the node Cilium chose for the Service.

The lab used to run Traefik with its own CRDs (IngressRoute, Middleware, and friends). Gateway API standardises routes; Envoy Gateway is the controller here — one Helm install, three shared Gateways, and per-app HTTPRoute resources instead of Traefik-only objects.

Traefik is excellent at the edge, but its CRDs are controller-specific. Moving to Gateway API was less about feature envy and more about portability: the same HTTPRoute can be read by another implementation if you ever switch controllers. Envoy Gateway is the implementation here; the routes stay standard Kubernetes objects.

For images you build yourself, a practical supply-chain loop is: build in CI, sign the digest, verify at admission. The lab uses Cosign (Sigstore), a private Zot registry at oci.this-is-fine.io, and Kyverno verifyImages so unsigned ZeroClaw pods do not start.

CI holds the private signing key; the cluster policy carries the matching public key.

Signing answers a simple question: did this image come from your build pipeline? Scanning for CVEs is still worth doing, but signature verification stops casual image substitution even when a tag name looks familiar.

Mastodon is a federated microblog server: local timelines plus ActivityPub links to other instances. Running it means managing state (PostgreSQL, media, cache) and edge (HTTPS and /.well-known for discovery). The lab instance is at https://mastodon.this-is-fine.social.

It ships as a Helm release through Flux, same GitOps style as the rest of the lab.

Federation is the interesting part socially and technically. Other servers discover you through HTTPS hostnames and /.well-known endpoints; if DNS or TLS drifts, federation breaks even when the pod is healthy. That is why the lab treats edge (Gateway API, cert-manager, external-dns) as first-class dependencies, not an afterthought.

IRC is still a simple model: one server, many channels, text over a long-lived TCP session. InspIRCd runs the network; ZNC is a bouncer that stays logged in when your client disconnects and replays backlog when you return.

In the lab both are plain Deployments under Flux, with TLS from cert-manager and a Gateway API TCPRoute for TLS on port 6697.

IRC is a good contrast to HTTP-only homelab apps: clients expect a long-lived TCP session and often TLS on a non-443 port. Gateway API TCPRoute covers that without bolting IRC into an HTTP ingress controller as a special case.

Tailscale builds a WireGuard mesh with little configuration. Headscale is an open control server for the same clients — you run policy and issue keys yourself. The lab does not use the Tailscale Kubernetes operator; a handful of Deployments and DaemonSets do the job instead.

The goal is one tailnet for laptops and nodes, with Kubernetes APIs and internal HTTP on *.tif.internal without putting those names on the public internet.

Self-hosting the control plane means you own ACL files, preauth keys, and MagicDNS base domains. The trade-off is operational work: upgrades, backups, and policy edits are yours. For a multi-cluster lab that already runs GitOps everywhere else, that trade-off is acceptable.

Stateful apps need point-in-time copies and a copy off the cluster. The lab uses VolSync with the restic mover: Kubernetes creates a VolumeSnapshot, VolSync runs restic against it, and encrypted data lands in a remote repository. The restic URL and password live in Vault and reach the cluster through External Secrets.

VolSync sits in the middle: you already run the CSI snapshot controller and a storage class that supports snapshots (Rook-Ceph block volumes in the lab). VolSync watches a ReplicationSource, triggers on a schedule, and spins up a short-lived mover job. You get off-site copies without shelling into pods to run restic by hand.
